A newer version of this model is now available
This model has been replaced by a newer model, the ACTstation x110.
-
CPU
1x up to 22 core Intel Xeon E5v4 (Broadwell)
-
MEMORY
8x DDR4 2400MHz DIMM sockets (Max: 256 GB)
-
STORAGE
8x 3.5" & 8x 2.5" SATA,SSD drive bays (Max: 80 TB)
-
ACCELERATORS
Max 2x NVIDIA Quadro, NVIDIA GTX accelerators
-
CONNECTIVITY
Onboard 2x 1Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, OmniPath, 100GbE
-
DENSITY
Desktop chassis
Discounts are available for volume, education and government customers. Request a quote for product and pricing details.
Technical Specifications
In the box
- Workstation system
- Optional keyboard and optical mouse
- 110V or 208V power cord
- Documentation
Processor
- Closed loop water cooling system for maximum performance and minimal noise
- Intel Xeon E5-1600v3 series processor
- Intel "Haswell" microarchitecture
- Integrated memory controller and 2x QPI interconnects per socket
- 22nm process technology
Accelerators
- Space for up to 2x GPUs or Xeon Phi
Chipset
- Intel C610 series
Memory
- 2400MHz DDR4 memory
- 8x DIMM sockets for support up to 256GB
Storage
- 8x 3.5" / 2.5" drive bays
- Support for high-performance solid state drives (SSD)
- Support RAID level 0,1,10,5,6 with Linux software RAID or optional hardware RAID controller
- 2x 5.25" external drive bay for CD/DVD drive
Management
- Integrated IPMI 2.0 module
- Integrated management controller providing iKVM and remote disk emulation
I/O Connections
- 2x open PCI-e 3.0 expansion slots running at 16x; 2x open PCI-e 3.0 expansion slots running at 8x
- 2x independent 1Gb RJ-45 ethernet interfaces
- 4x USB 3.0 ports, 4x USB 2.0 ports
- 1x VGA port (more with optional dedicated GPU)
Electrical requirements
- High-efficiency power supply (greater than 80%)
- Output power: 860W power supply
- Universal input voltage 100V to 240V
- Frequency: 50Hz to 60Hz, single phase
Size & Weight
- Height: 17.7 inches
- Width: 9.1 inches
- Depth: 20.5 inches
- Weight: Base config 40lbs, varies based on configuration
Operating System
- RedHat Linux 6 and newer (most other distributions supported, call for details)
- Windows 2008 and newer
