A newer version of this model is now available
This model has been replaced by a newer model, the ACTserv e4411c.
-
CPU
1x up to 64 core AMD EPYC (Milan/Milan-X)
-
MEMORY
8x DDR4 3200MHz DIMM sockets (Max: 1 TB)
-
STORAGE
4x 3.5"SATA,SSD drive bays (Max: 38.72 TB)
-
ACCELERATORS
Max 4x NVIDIA Tesla accelerators
-
CONNECTIVITY
Onboard 2x 1Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, OmniPath, 100GbE
-
DENSITY
2U rackmount chassis with redundant power
Discounts are available for volume, education and government customers. Request a quote for product and pricing details.
Technical Specifications
In the box
- ACTserv e2280c system
- Documentation
Processor
- 1x AMD EPYC 7003 series processors
- AMD EPYC "Milan" microarchitecture
Accelerators
- Up to 4 x NVIDIA ® PCIe Gen4 GPU cards
Chipset
- System on Chip
Memory
- 3200MHz DDR4 memory
- 8x DIMM sockets for support up to 1024GB
Storage
- Front side: 4 x 3.5" SATA hot-swappable HDD/SSD bays
- 2.5" HDD/SSD supported
- SATA devices supported only
Management
- Integrated IPMI 2.0 module
- Integrated management controller providing iKVM and remote disk emulation
I/O Connections
- 4x PCIe Gen 4.0 x16 for GPUs, 1x PCIe Gen 4.0 x16 (or 2x x8)
Electrical requirements
- 2 x 1600W redundant PSUs
- 80 PLUS Platinum
Size & Weight
- Height: 3.5 inches (2U)
- Width: 3.5 inches
- Depth: 32 inches
- Weight: Base config 65lbs, varies based on configuration
Operating System
- RedHat Linux 7.6 and newer (most other distributions supported, call for details)
