A newer version of this model is now available
This model has been replaced by a newer model, the ACTserv e2280c.
-
CPU
1x up to 32 core AMD EPYC (Naples)
-
MEMORY
8x DDR4 2666MHz DIMM sockets (Max: 512 GB)
-
STORAGE
8x 3.5"SATA,SSD drive bays (Max: 38.72 TB)
-
ACCELERATORS
Max 8x NVIDIA Tesla accelerators
-
CONNECTIVITY
Onboard 2x 1Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, OmniPath, 100GbE
-
DENSITY
2U rackmount chassis with redundant power
Discounts are available for volume, education and government customers. Request a quote for product and pricing details.
Technical Specifications
In the box
- ACTserv e2180c system
- Documentation
Processor
- 1x AMD EPYC 7001 series processors
- AMD EPYC "Naples" microarchitecture
Accelerators
- Up to 8x dual height, full length GPUs (NVIDIA Tesla)
Chipset
- AMD EPYC SoC
Memory
- 2666MHz DDR4 memory
- 8x DIMM sockets for support up to 512GB
Storage
- 8x 2.5" hot-swap SATA drive bay
- Support RAID level 0,1,10,5,6 with Linux software RAID or optional hardware RAID controller
- Support for high-performance solid state drives (SSD)
Management
- Integrated IPMI 2.0 module
- Integrated management controller providing iKVM and remote disk emulation
I/O Connections
- 8x PCIe x16 for GPUs, 2x PCIe x16 HL/LP
Electrical requirements
- High-efficiency redundant 2200W power supply (greater than 90%)
- Universal input voltage 100V to 240V
Size & Weight
- Height: 3.5 inches (2U)
- Width: 19 inches
- Depth: 28 inches
- Weight: Base config 65lbs, varies based on configuration
Operating System
- RedHat Linux 7 and newer (most other distributions supported, call for details)
